Technical Specification
Normal Size Range: 2"-40"
Normal Pressure Rating: PN10~PN16, CLASS150~300
Material: WCB, CF8,CF8M,CF3,CF3M
Operation: Handwheel, Pneumatic, Electric
Temperature Range: -29~425 Degree C
Standards compliance
Design and Manufacture: GB/T12228, API609
Face to face(end to end): GB/T12221
Flanged connection: ANSI B16.5, GB/T 9113
Test and inspection: API 598, GB/T 13927
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 2"~120" (DN50~DN3000).
End connection: Wafer, Lug, Flanged.
Pressure range: 150lbs~600lbs(PN16~PN100).
Operation: Wrench, Gearbox, Electric.
Working temperature: -46℃~ 200℃.
