Technical Specification
Normal Size Range: 1/2"-14"
Normal Pressure Rating: PN10~PN150, CLASS150~900
Material: WCB,LCB,WC6,CF8,CF8M,CF3,CF3M
Temperature Range: -29~180 Degree C
Standards compliance
Design and Manufacture: API 599,API 6D
Face to face(end to end): ANSI B 16.10
Flanged connection: ANSI B16.5
Butt welded end: ANSI B16.25
Test and inspection: API 598
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 1/2"~16" (DN15~DN400).
End connection: BW, Flanged.
Pressure range: 150lbs~600lbs (PN16~PN100).
Operation: Handwheel, Gearbox, Electric, Pneumatic, Electro hydraulic actutor, Gas over oil actuator.
Working temperature: -29℃~ 180℃.
